| Brand Name: | SUNHOUSE |
| Model Number: | awp-08 |
| MOQ: | 3000pcs |
| Delivery Time: | 15days |
| Payment Terms: | T/T |
Carbon Crystal Wall Panels are high-performance decorative wall systems engineered for modern hospitality and commercial spaces. Featuring a 9mm thickness with a multi-layer composite structure, these panels integrate carbon crystal technology for enhanced durability and eco-friendly performance. The core material combines recycled wood fibers and resin-free bonding agents, achieving E1 environmental certification. Ideal for hotel renovations, the panels deliver superior soundproofing (up to 32dB reduction) while maintaining a sleek, seamless appearance.
| Item | Parameters |
|---|---|
| Material | Bamboo charcoal fiber, PP/PVC resin, calcium powder, additives, etc. |
| Layer Structure | 7-layer composite (protective layer, surface film layer, UV-cured layer, PP co-extruded layer, carbon crystal layer, etc.) |
| Standard Sizes | - Thickness: 5/8" (≈15.8mm), 8mm, 12mm - Dimensions: 1220×2440mm, 1220×2600mm (customizable) |
| Density | Approximately 0.8–1.2 g/cm³ |
| Fire Rating | Class B1 (flame-retardant), some premium products achieve Class A1 (non-combustible) |
| Sound Insulation | 29 dB (equivalent to solid wall insulation) |
| Thermal Conductivity | ≤0.03 W/(m·K) (excellent heat insulation) |
| Water Absorption | ≤0.1% (outstanding moisture resistance) |
| Surface Hardness | Pencil hardness ≥2H (scratch-resistant) |
| Nail Holding Power | ≥1500N (direct nailing/screwing supported) |
|
|
| Brand Name: | SUNHOUSE |
| Model Number: | awp-08 |
| MOQ: | 3000pcs |
| Packaging Details: | 1220*2440mm |
| Payment Terms: | T/T |
Carbon Crystal Wall Panels are high-performance decorative wall systems engineered for modern hospitality and commercial spaces. Featuring a 9mm thickness with a multi-layer composite structure, these panels integrate carbon crystal technology for enhanced durability and eco-friendly performance. The core material combines recycled wood fibers and resin-free bonding agents, achieving E1 environmental certification. Ideal for hotel renovations, the panels deliver superior soundproofing (up to 32dB reduction) while maintaining a sleek, seamless appearance.
| Item | Parameters |
|---|---|
| Material | Bamboo charcoal fiber, PP/PVC resin, calcium powder, additives, etc. |
| Layer Structure | 7-layer composite (protective layer, surface film layer, UV-cured layer, PP co-extruded layer, carbon crystal layer, etc.) |
| Standard Sizes | - Thickness: 5/8" (≈15.8mm), 8mm, 12mm - Dimensions: 1220×2440mm, 1220×2600mm (customizable) |
| Density | Approximately 0.8–1.2 g/cm³ |
| Fire Rating | Class B1 (flame-retardant), some premium products achieve Class A1 (non-combustible) |
| Sound Insulation | 29 dB (equivalent to solid wall insulation) |
| Thermal Conductivity | ≤0.03 W/(m·K) (excellent heat insulation) |
| Water Absorption | ≤0.1% (outstanding moisture resistance) |
| Surface Hardness | Pencil hardness ≥2H (scratch-resistant) |
| Nail Holding Power | ≥1500N (direct nailing/screwing supported) |
